Table Top Electro Mechanical Coder

Table Top Electro Mechanical Coder

Product Code: EQUP-MC20087-0033

Categories: Bottle Filling and Batch Coding Machinery

Tags: Table Top Electro Mechanical Coder

1014

Download PDF Enquire Now
  • Description

Table Top Electro Mechanical Coder



Specification

Capacity    20 per minute
Print Speed    Motorizd
Type    Table Top

Available in two and EMC-100, these use ink paste as their inking medium. In addition to this, these have marvelous construction are based on the DC stepper motors. Finally, these are quite easy to maintain and install.

Features:


  • DC Stepper motor based very compact, lightweight and portable design. Can be used as a replacement for Electro-Pneumatic coders (does not require compressor) for Packaging Machine mounting also
  • Low cost machine with very low operating and inventory costs. Uses standard grooved or flat stereos and fast drying coding ink
  • In built timer for automatic timed operation (settable) or can be connected to any sensor or foot switch for controlled operation
  • Imported motor and accessories provide reliability & long life
Supply Voltage 230 Vac ± 10%, 15 VA
Printing Area 4 to 6 lines (35 X 35 mm.)
Printing Speed Max. 80 imprints / min.
Prints using Easily Changeable grooved / flat, rubber / nylon stereos
Inking Medium Special rechargeable ink / wax cartridge / ink paste
Printing Medium Quick drying liquid ink (Black, Red, White*, Golden*, etc.)
Impressions 15,000 per 20 ml. charge
Weight 7 Kgs, 3 Kgs (Only head)
