Table Top Electro Pneumatic Coder

Table Top Electro Pneumatic Coder

Product Code: EQUP-MC20087-0030

Categories: Bottle Filling and Batch Coding Machinery

Tags: Table Top Electro Pneumatic Coder

1011

Download PDF Enquire Now
  • Description

Table Top Electro Pneumatic Coder



Specification

Print Speed    Pneumatic
Capacity    As per Machine
Type    Semi Automatic
Uses    Table Top

Table Top Electro Pneumatic Coder, which can be connected to any sensor, limit switch, etc. for online controlled operation or to timer for automatic timed operation Imported pneumatic accessories provide reliability, long life and speeds upto 150 impressions per minute.

Features:

  • Electro-pneumatic cylinder based very compact design. Can be very easily installed on existing packaging machinery with bracket supplied suitable for all machine models
  • Low cost machine with very low operating and inventory costs. Uses standard grooved or flat stereos and fast drying coding ink
  • Can be connected to any sensor, limit switch, etc. for online controlled operation or to timer for automatic timed operation
  • Imported pneumatic accessories provide reliability, long life and speeds upto 150 impressions per minute
Supply Voltage 230 Vac ± 10%, 10 VA
Printing Area 6 to 8 Lines (50 X 100 mm.)
Printing Speed Max. 100 imprints / min.
Prints using Easily Changeable grooved / flat, rubber / nylon stereos
Inking Medium Special rechargeable ink / wax cartridge / ink paste
Printing Medium Quick drying liquid ink (Black, Red, White*, Golden*, etc.)
Impressions 10,000 per 60 ml. charge
Weight 10 Kgs, 5 Kgs (Only head)
