Steam Air Defroster

Steam Air Defroster

The heating system is electrical,
Humidification system: double: water spray + steam generator (10kg / h),
Dimensions of the room for defrosting 6000mm (length) x 3000mm (width) x 3500mm (height),
Rack dimensions: 900 mm (width) x 1620 mm (length) x 1600 mm (height) – 6 levels,
Ventilation: variable flow direction in time, possibility of smooth adjustment.
Installed power:
The fan is 4.8 kW,
heating – 54.0 kW,
steam generator – 7,5 kW,
drive for changing the flow direction – 0,75 kW
Full power: 67,0 kW
Control: microprocessor
Measurement and temperature control inside the defroster,
Block temperature measurement,
Measurement of relative humidity
