Fruit Pitting and Pulping Machine

Fruit Pitting and Pulping Machine

Product Code: EQUP-MC20088-0009

Categories: Fruit Processing Equipment

Tags: Fruit Pitting and Pulping Machine

776

Download PDF Enquire Now
  • Description

Fruit Pitting and Pulping Machine



Specification

Product performance characteristics
1. This machine is used for beating, peeling and enucleation of fruits and vegetables. It is mainly suitable for denucleating pulping after pre-cooking or eight mature stone fruits. The pulp, slag and core are automatically separated, and the core is peeled and peeled. Separation of the pulp. It is suitable for the processing of stone fruit fruits such as mango, apricot, peach and plum.
2. Automatic cleaning interface, built-in multi-angle sprinkler, high degree of cleaning automation;
3. The overall frame and the contact part with the material are made of high quality 304 stainless steel material;
4. The movable door of the nuclear outlet is designed with a unique hinge mechanism, and the cleaning and replacement of the screen is extremely convenient;
5. The equipment is stable in operation and can be installed on the assembly line for automated production;

Description

Dimensions(mm)

Suggested capacity

Suggested power

The capacity and power are determined on different raw fruits

All made of SUS304 stainless steel,Rotating at 960- 1350 rpm

1170x1000x1250

≤2t/h

5.5

1760x1200x1500

3-5t/h

15

1950x1400x1680

6-10t/h

22

2150x1650x1880

11-15t/h

30
