On Line Coder For Packaging Machines

On Line Coder For Packaging Machines

Product Code: EQUP-MC20087-0018

Categories: Bottle Filling and Batch Coding Machinery

Tags: On Line Coder For Packaging Machines

999

Download PDF Enquire Now
  • Description

On Line Coder For Packaging Machines



Specification

Capacity    20 per minute
Print Speed    Motorized
Type    Machine Mount

The PLC or controller takes the signal from the print sensor proximity or eye mark sensor & gives signal to the DC Stepper Motor to turn the print drum automatically at the synchronized speed with the film to do the coding/printing at the exact location. The PLC also displays the no. of prints that have taken place & the linear speed of web in meters/min.

Features:

  • First time direct replacement for Ink Jet Printers. No need to stop the process for printing as printing is on-line and continuous at very high printing / production speeds up to 350 impressions / minute
  • No need for any operator settings as it automatically tracks the speed of the packaging machine and varies its own speed to match it. Absolute accurate location in printing repeatedly
  • Bright LED display for 6 digit production counter as well as for display of speed of film in meters / minute and pouches / minute
  • Can be quickly installed on existing biscuit / spice / milk / oil / coffee / detergent pouch filling machines & other packaging machines within 15 minutes with the specially designed bracket
Supply Voltage 230 Vac ± 10%, 25 VA
Printing Area 6 lines (35 X 200 mm)
Printing Speed Max. 30 Meters / min.
Prints using Easily Changeable grooved/flat, rubber / nylon stereos
Inking Medium Special rechargeable ink cartridge / ink paste.
Printing Medium Quick drying liquid ink (Black, Red, White*, Golden*, etc.)
Impressions 15,000 per 20 ml. charge
Weight 7 Kgs, 5 Kgs (Only head)
