Ink Jet Printer
Specification
Print Method HP Cartridge
Capacity 500 pieces per minute
Automation Grade Semi-Automatic
Color & Page Single Color
Country of Origin Made in India
Type Inkjet
Uses Ink
Industrial Handheld Non-Contact Large Character Ink Jet Printer which is a Zero Maintenance, Battery Powered TWO line (character height 20 to 50 mm) Printer & can be used on Porous / Non-Porous products to print B.No., Exp.Date, Time, Serial No. on labels, cartons, pouches, drums, containers, etc. It is an ultra-compact portable and light inkjet printer equipped with a print-head with electromagnetic valves. It is battery operated and Bluetooth controlled & is fully programmable through PC with user-friendly software where it can print 2 lines Data & all Computer Fonts (local languages) at a very low price. It is also capable of printing Multi-Segment messages.
| Display |
2 digit LED display for Message No. |
| Input Device |
Bluetooth Communication with Computer Software. |
| Printable Images |
Alphanumeric, Logo, Date/Time, Counter, etc. |
| Printing Area |
1 to 2 lines of 120 char. each from 20 to 50 mm high. |
| Printing Matrix |
5 × 5, 5 × 7, 10 × 10, 10 × 16, 16 × 16 |
| Message Capacity |
16 memory location, 150 characters (5 × 7) per message, 75 characters (16 ×16) per message |
| Printing Speed |
Max. 40 meters/min for 1 to 2 line printing |
| Prints Using |
16 Nozzle electromagnetic valve Print-head for spraying ink |
| Print Distance |
Max. 25 mm from substrate. |
| Inking Medium |
150 cc ink in Cartridge form, 250 g ± 5 g |
| Printing Medium |
MEK / Solvent / Oil based inks (black, red*, blue*, white*, etc.) |
| Ink Drying Time |
Min. 10 seconds on plastics & laminates. |
| Impressions |
Appx. 4 million char. of 2 mm per cartridge of ink. |
| Operating Range |
5 ~ +45ºC, 10% - 90% RH, non-condensing. |
| Supply Voltage |
12 V ± 5%, Charger: 12.6 V / 1A DC |
| Dimensions |
212 x 135 x 120 mm |
| Weight |
1.5 Kg ± 10 g including full ink cartridge & battery. |
