Horizontal Motorized Coding Machine
Capacity 20 per minute
Print Speed Motorized Type
Type Horizontal Profile Printer
Horizontal Motorized ompact, fully automatic PLC based printer for 1 to 4 lines printing of ISI mark, Mfg. Dt.,
Company Name, Logos, etc. on all types of rigid or soft type PVC / Plastic Profiles, Casing Patty, etc. of width 20 mm to 200 mm during extrusion process. The message to be printed is very easily composed by just sticking the low-cost rubber / nylon stereos (easily changeable) on to the print wheel. The inking is in the form of rechargeable cartridge, so colour of printing can be changed easily by changing cartridge. The PLC has a bright LED display to set the printing repeat from 0.5 Meter to 25 Meters. It also displays the length of Profile extruded, no. of prints that have taken place & the linear speed of extrusion in meters / min.
Also, a production length can be set & it can give an alarm & relay signal after the preset length of Profile has been extruded. (Free accessories include 1 Lit. Blue Ink, 1 Lit. Solvent, 6 mm Flat Rubber Character Set, Double Sided Tape & Ink Cartridge). These coders are ideal for Automatic On-Line Coding on various types of Profiles & Casing Patty during their extrusion process or as off-line printers also for manual printing.
Supply Voltage | 230 Vac ± 10%, 25 VA |
Printing Area | 1 to 4 Lines (max. 35 X 400mm) |
Printing Repeat | Settable From PLC |
Prints Using | Flat rubber / naylon Stereos. |
Inking Medium | Rechargeable ink Cartridge |
Printing Medium | Fast Drying Liquid ink (Black, Red, Blue, White* Golden/ etc) |
Impressions | 2,000 per 20 ml. Charge with continuous ink drip system |
Weight (kgs) | 50kgs |
