Product Code: EQUP-MC20087-0037

Categories: Bottle Filling and Batch Coding Machinery

Tags: Contact Coder

1018

Download PDF Enquire Now
  • Description

Contact Coder



Specification

Capacity    100 per minute
Print Speed    100 per minute
Features:

  • DC Stepper motor based very compact, lightweight and portable design. Can be used as a replacement for Electro-Pneumatic coders (does not require compressor) for Packaging Machine mounting also
  • Low cost machine with very low operating and inventory costs. Uses standard grooved or flat stereos and fast drying coding ink
  • In built timer for automatic timed operation (settable) or can be connected to any sensor or foot switch for controlled operation
  • Imported motor and accessories provide reliability & long life
Supply Voltage 230 Vac ± 10%, 20 VA
Printing Area 6 to 8 Lines (50 X 100 mm.)
Printing Speed Max. 50 imprints / min.
Prints using Easily Changeable grooved / flat, rubber / nylon stereos
Inking Medium Special rechargeable ink / wax cartridge / ink paste
Printing Medium Quick drying liquid ink (Black, Red, White*, Golden*, etc.)
Impressions 10,000 per 60 ml. charge
Weight 11 Kgs, 6 Kgs (Only head)
