Automatic Plastic Metal Cap Locking Machine

Automatic Plastic Metal Cap Locking Machine

Product Code: EQUP-MC20087-0064

Categories: Bottle Filling and Batch Coding Machinery

1045

Download PDF Enquire Now
  • Description

Automatic Plastic Metal Cap Locking Machine



Specification

Packaging Type    Wooden Crate
Voltage    230 Vac
Finish    SS
Conveyor Height    900 mm

for automatically fixing the caps onto PET or Glass type bottles moving on conveyor. The capping machine is ideal for application in pharmaceutical, food, pesticides, cosmetic & other Industries. Machine is equipped with vibratory type bowl feeder depending on cap shape and size for continuous feeding of cap for online operation on any liquid of powder filling line. Machine is suitable for various sizes of bottles and ROPP cap with the help of change parts.


Specifications:

  • Power supply: 440 Volts, 3 Phase, 1.5 H.P
  • Sealing speed: 1200 Bottles / hr.
  • Container Diameter: 24mm to 90mm
  • Container Height: 50mm to 250mm
  • Cap Diameter: 20mm, 25mm & 28mm with change parts
  • Conveyor Height: 800mm to 900mm adjustable
  • Overall Dimension: 1400mm (L) X 900mm (W) X 1800mm (H)
